>ALOS Data Take Simulation(Jun. 01, 2008)

Observation Area

PRISM

AVNIR-2

PALSAR

Observation Plan

No.SensorModeStart DateEnd Date Obs. Time Start Path Start Arg. Lat. End Path End Arg. Lat. Angle Tbable
1AV2OBS2008-06-01 00:15:042008-06-01 00:16:58 00:01:54 30 169.33 30 176.26 0.00 -
2PSMOB12008-06-01 00:21:502008-06-01 00:29:56 00:08:06 30 194.01 30 223.55 1.20 -
3PSRWB12008-06-01 00:22:392008-06-01 00:29:09 00:06:30 30 196.98 30 220.69 27.10 80
4PSRFBD2008-06-01 01:04:112008-06-01 01:06:21 00:02:10 30 348.45 30 356.35 34.30 43
5PSRFBS2008-06-01 01:20:492008-06-01 01:26:59 00:06:10 76 49.05 76 71.54 34.30 7
6PSRWB12008-06-01 01:27:472008-06-01 01:34:41 00:06:54 76 74.52 76 99.68 27.10 80
7AV2OBS2008-06-01 01:36:192008-06-01 01:40:37 00:04:18 76 105.63 76 121.31 0.00 -
8PSRWB12008-06-01 01:46:052008-06-01 01:50:01 00:03:56 76 141.25 76 155.59 27.10 80
9AV2OBS2008-06-01 01:46:102008-06-01 01:48:26 00:02:16 76 141.55 76 149.82 0.00 -
10PSMOB22008-06-01 01:46:172008-06-01 01:48:37 00:02:20 76 141.98 76 150.49 0.00 -
11AV2OBS2008-06-01 01:55:032008-06-01 01:57:51 00:02:48 76 173.89 76 184.10 0.00 -
12PSMOB12008-06-01 01:59:402008-06-01 02:07:40 00:08:00 76 190.79 76 219.96 1.20 -
13AV2OBS2008-06-01 02:01:472008-06-01 02:07:39 00:05:52 76 198.50 76 219.90 0.00 -
14PSRFBD2008-06-01 02:46:302008-06-01 02:50:16 00:03:46 122 1.58 122 15.32 34.30 43
15PSRPLR2008-06-01 02:56:492008-06-01 02:58:41 00:01:52 122 39.20 122 46.01 21.50 127
16PSRFBS2008-06-01 03:00:382008-06-01 03:04:30 00:03:52 122 53.12 122 67.22 34.30 7
17PSRWB12008-06-01 03:16:342008-06-01 03:19:30 00:02:56 122 111.23 122 121.92 27.10 80
18PSMOB12008-06-01 03:20:202008-06-01 03:25:26 00:05:06 122 124.96 122 143.56 1.20 -
19AV2OBS2008-06-01 03:21:072008-06-01 03:26:43 00:05:36 122 127.76 122 148.18 0.00 -
20PSRWB12008-06-01 03:21:502008-06-01 03:23:42 00:01:52 122 130.43 122 137.24 27.10 80
21PSRWB12008-06-01 03:28:162008-06-01 03:33:54 00:05:38 122 153.89 122 174.44 27.10 80
22PSMOB12008-06-01 03:28:262008-06-01 03:36:04 00:07:38 122 154.50 122 182.34 1.20 -
23AV2OBS2008-06-01 03:28:512008-06-01 03:37:23 00:08:32 122 155.96 122 187.08 0.00 -
24AV2OBS2008-06-01 03:41:442008-06-01 03:43:36 00:01:52 122 202.94 122 209.75 21.50 -
25PSRFBD2008-06-01 04:08:102008-06-01 04:14:14 00:06:04 122 299.40 122 321.52 34.30 43
26PSRFBD2008-06-01 04:25:522008-06-01 04:30:06 00:04:14 168 3.95 168 19.39 34.30 43
27PSRFBD2008-06-01 04:31:162008-06-01 04:37:40 00:06:24 168 23.64 168 46.98 34.30 43
28PSRFBS2008-06-01 04:40:592008-06-01 04:46:17 00:05:18 168 59.02 168 78.34 34.30 7
29PSRWB12008-06-01 04:55:152008-06-01 04:58:11 00:02:56 168 111.10 168 121.80 27.10 80
30PSMOB12008-06-01 04:59:062008-06-01 05:13:06 00:14:00 168 125.08 168 176.14 1.20 -
31AV2OBS2008-06-01 04:59:492008-06-01 05:06:33 00:06:44 168 127.70 168 152.25 0.00 -
32PSRFBS2008-06-01 05:04:012008-06-01 05:06:47 00:02:46 168 143.01 168 153.10 34.30 7
33PSRFBD2008-06-01 06:10:132008-06-01 06:16:23 00:06:10 214 24.43 214 46.92 34.30 43
34PSRFBS2008-06-01 06:21:032008-06-01 06:25:27 00:04:24 214 63.94 214 79.99 34.30 7
35PSRWB12008-06-01 06:26:392008-06-01 06:29:09 00:02:30 214 84.36 214 93.48 27.10 80
36PSMOB12008-06-01 06:37:492008-06-01 06:49:03 00:11:14 214 125.08 214 166.05 1.20 -
37AV2OBS2008-06-01 06:38:312008-06-01 06:48:17 00:09:46 214 127.70 214 163.31 0.00 -
38AV2OBS2008-06-01 06:56:032008-06-01 07:00:25 00:04:22 214 191.58 214 207.50 0.00 -
39PSRWB12008-06-01 07:53:232008-06-01 08:00:47 00:07:24 260 40.66 260 67.65 27.10 80
40PSRWB12008-06-01 08:03:502008-06-01 08:07:23 00:03:33 260 78.83 260 91.78 27.10 80
41AV2OBS2008-06-01 08:09:322008-06-01 08:11:24 00:01:52 260 99.56 260 106.36 0.00 -
42PSMOB12008-06-01 08:13:422008-06-01 08:25:26 00:11:44 260 114.75 260 157.54 1.20 -
43AV2OBS2008-06-01 08:18:372008-06-01 08:33:13 00:14:36 260 132.74 260 185.98 0.00 -
44AV2OBS2008-06-01 08:35:582008-06-01 08:41:38 00:05:40 260 195.95 260 216.62 0.00 -
45PSRWB12008-06-01 08:36:072008-06-01 08:38:01 00:01:54 260 196.50 260 203.43 27.10 80
46PSRFBD2008-06-01 09:17:142008-06-01 09:19:06 00:01:52 260 346.44 260 353.25 34.30 43
47PSRFBD2008-06-01 09:21:042008-06-01 09:22:56 00:01:52 306 0.43 306 7.23 34.30 43
48PSMOB12008-06-01 09:50:052008-06-01 10:01:13 00:11:08 306 106.24 306 146.84 1.20 -
49AV2OBS2008-06-01 09:50:142008-06-01 09:52:06 00:01:52 306 106.79 306 113.60 0.00 -
50AV2OBS2008-06-01 10:02:442008-06-01 10:06:36 00:03:52 306 152.43 306 166.53 0.00 -
51PSRFBD2008-06-01 10:53:452008-06-01 10:55:37 00:01:52 306 338.42 306 345.22 34.30 43
52PSRFBD2008-06-01 10:58:302008-06-01 11:00:22 00:01:52 306 355.74 352 2.55 34.30 43
53PSRFBD2008-06-01 11:13:462008-06-01 11:16:40 00:02:54 352 51.42 352 61.99 34.30 43
54PSMOB12008-06-01 11:30:422008-06-01 11:35:54 00:05:12 352 113.17 352 132.13 1.20 -
55AV2OBS2008-06-01 11:41:262008-06-01 11:46:06 00:04:40 352 152.31 352 169.33 0.00 -
56PSMOB12008-06-01 12:02:532008-06-01 12:05:29 00:02:36 352 230.53 352 240.02 1.20 -
57PSRFBD2008-06-01 12:33:592008-06-01 12:37:27 00:03:28 352 343.95 352 356.59 34.30 43
58PSRFBS2008-06-01 12:49:312008-06-01 12:51:43 00:02:12 398 40.60 398 48.62 34.30 7
59PSMOB12008-06-01 13:26:482008-06-01 13:38:28 00:11:40 398 176.56 398 219.11 1.20 -
60PSRWB12008-06-01 13:55:432008-06-01 13:57:39 00:01:56 398 282.08 398 289.13 27.10 80
61PSRFBS2008-06-01 14:11:332008-06-01 14:13:35 00:02:02 398 339.75 398 347.17 34.30 7
62PSRFBD2008-06-01 14:15:282008-06-01 14:31:20 00:15:52 398 354.04 444 51.91 34.30 43
63PSRWB12008-06-01 14:32:402008-06-01 14:35:38 00:02:58 444 56.77 444 67.59 27.10 80
64PSRWB12008-06-01 14:37:262008-06-01 14:44:02 00:06:36 444 74.15 444 98.22 27.10 80
65AV2OBS2008-06-01 14:43:432008-06-01 14:49:31 00:05:48 444 97.06 444 118.22 0.00 -
66AV2OBS2008-06-01 14:51:122008-06-01 14:53:52 00:02:40 444 124.35 444 134.08 0.00 -
67PSMOB12008-06-01 15:01:562008-06-01 15:12:18 00:10:22 444 163.50 444 201.30 1.20 -
68AV2OBS2008-06-01 15:09:402008-06-01 15:11:32 00:01:52 444 191.70 444 198.50 0.00 -
69PSRFBD2008-06-01 15:55:052008-06-01 15:58:25 00:03:20 444 357.32 490 9.48 34.30 43
70PSRFBD2008-06-01 16:00:232008-06-01 16:10:03 00:09:40 490 16.65 490 51.91 34.30 43
71PSRWB12008-06-01 16:11:232008-06-01 16:14:21 00:02:58 490 56.77 490 67.59 27.10 80
72PSMOB12008-06-01 16:19:542008-06-01 16:28:58 00:09:04 490 87.83 490 120.89 1.20 -
73AV2OBS2008-06-01 16:27:102008-06-01 16:42:24 00:15:14 490 114.33 490 169.88 0.00 -
74PSRFBD2008-06-01 17:37:032008-06-01 17:48:47 00:11:44 536 9.18 536 51.97 34.30 43
75AV2OBS2008-06-01 18:01:112008-06-01 18:13:47 00:12:36 536 97.12 536 143.07 0.00 -
76PSMOB12008-06-01 18:04:122008-06-01 18:17:52 00:13:40 536 108.19 536 158.03 1.20 -
77PSRFBS2008-06-01 18:45:522008-06-01 18:47:46 00:01:54 536 260.13 536 267.06 34.30 7
78PSRFBS2008-06-01 18:49:132008-06-01 18:51:25 00:02:12 536 272.35 536 280.37 34.30 7
79PSRFBD2008-06-01 18:58:092008-06-01 19:00:01 00:01:52 536 304.93 536 311.74 34.30 43
80PSRFBD2008-06-01 19:14:362008-06-01 19:25:54 00:11:18 582 4.92 582 46.13 34.30 43
81PSRWB12008-06-01 19:31:242008-06-01 19:34:50 00:03:26 582 66.19 582 78.71 27.10 80
82PSMOB12008-06-01 19:37:002008-06-01 19:49:18 00:12:18 582 86.55 582 131.40 1.20 -
83AV2OBS2008-06-01 19:38:262008-06-01 19:43:58 00:05:32 582 91.84 582 112.02 0.00 -
84AV2OBS2008-06-01 20:06:192008-06-01 20:08:11 00:01:52 582 193.52 582 200.33 0.00 -
85PSRWB12008-06-01 20:21:012008-06-01 20:25:15 00:04:14 582 247.13 582 262.57 27.10 80
86PSRFBD2008-06-01 20:44:312008-06-01 20:57:07 00:12:36 582 332.83 628 18.78 34.30 43
87PSRFBD2008-06-01 21:02:302008-06-01 21:07:36 00:05:06 628 38.41 628 57.01 34.30 43
88PSMOB12008-06-01 21:15:422008-06-01 21:26:32 00:10:50 628 86.55 628 126.06 1.20 -
89PSRWB12008-06-01 21:22:262008-06-01 21:25:24 00:02:58 628 111.10 628 121.92 27.10 80
90PSMOB12008-06-01 21:42:572008-06-01 21:45:37 00:02:40 628 185.92 628 195.65 1.20 -
91AV2OBS2008-06-01 21:43:432008-06-01 21:45:35 00:01:52 628 188.72 628 195.53 0.00 -
92PSRFBS2008-06-01 21:51:162008-06-01 21:53:08 00:01:52 628 216.25 628 223.06 34.30 7
93AV2OBS2008-06-01 21:58:232008-06-01 22:01:11 00:02:48 628 242.20 628 252.42 0.00 -
94PSRFBD2008-06-01 22:31:072008-06-01 22:46:35 00:15:28 3 1.58 3 57.98 34.30 43
95PSRPLR2008-06-01 22:51:562008-06-01 22:53:48 00:01:52 3 77.49 3 84.30 24.20 129
96PSMOB12008-06-01 22:59:392008-06-01 23:07:15 00:07:36 3 105.63 3 133.35 1.20 -
97AV2OBS2008-06-01 23:05:112008-06-01 23:07:03 00:01:52 3 125.75 3 132.56 0.00 -
98AV2OBS2008-06-01 23:15:222008-06-01 23:21:30 00:06:08 3 162.89 3 185.25 0.00 -
99AV2OBS2008-06-01 23:23:122008-06-01 23:25:04 00:01:52 3 191.51 3 198.32 0.00 -
100AV2OBS2008-06-01 23:27:302008-06-01 23:31:12 00:03:42 3 207.13 3 220.63 -41.50 -
101PSRFBS2008-06-01 23:46:512008-06-01 23:49:13 00:02:22 3 277.76 3 286.39 34.30 7

Node information(Nominal Time)

PathAscending NodeDescending Node
LongitudeTime(UTC)LongitudeTime(UTC)
30-15.852382008-05-31 23:28:37151.807832008-06-01 00:17:58
76-40.531962008-06-01 01:07:20127.128252008-06-01 01:56:42
122-65.211552008-06-01 02:46:03102.448662008-06-01 03:35:25
168-89.891132008-06-01 04:24:46 77.769082008-06-01 05:14:08
214-114.570712008-06-01 06:03:29 53.089502008-06-01 06:52:51
260-139.250292008-06-01 07:42:12 28.409922008-06-01 08:31:34
306-163.929882008-06-01 09:20:55 3.730332008-06-01 10:10:17
352171.390542008-06-01 10:59:39-20.949252008-06-01 11:49:00
398146.710962008-06-01 12:38:22-45.628832008-06-01 13:27:43
444122.031382008-06-01 14:17:05-70.308422008-06-01 15:06:26
490 97.351792008-06-01 15:55:48-94.988002008-06-01 16:45:09
536 72.672212008-06-01 17:34:31-119.667582008-06-01 18:23:53
582 47.992632008-06-01 19:13:14-144.347162008-06-01 20:02:36
628 23.313042008-06-01 20:51:57-169.026752008-06-01 21:41:19
3 -1.366542008-06-01 22:30:40166.293672008-06-01 23:20:02
