>ALOS Data Take Simulation(Aug. 01, 2009)

Observation Area

PRISM

AVNIR-2

PALSAR

Observation Plan

No.SensorModeStart DateEnd Date Obs. Time Start Path Start Arg. Lat. End Path End Arg. Lat. Angle Tbable
1PSRWB12009-08-01 00:13:442009-08-01 00:17:28 00:03:44 28 180.09 28 193.70 27.10 80
2AV2OBS2009-08-01 00:22:262009-08-01 00:24:18 00:01:52 28 211.81 28 218.62 34.30 -
3PSRWB12009-08-01 00:31:272009-08-01 00:36:17 00:04:50 28 244.70 28 262.32 27.10 80
4PSRFBS2009-08-01 00:40:302009-08-01 00:42:48 00:02:18 28 277.70 28 286.09 34.30 7
5PSRFBD2009-08-01 01:00:132009-08-01 01:02:05 00:01:52 28 349.66 28 356.47 34.30 43
6PSMOB22009-08-01 01:32:042009-08-01 01:39:44 00:07:40 74 105.76 74 133.71 0.00 -
7AV2OBS2009-08-01 01:37:162009-08-01 01:39:04 00:01:48 74 124.72 74 131.28 0.00 -
8PSRFBS2009-08-01 01:38:142009-08-01 01:40:36 00:02:22 74 128.24 74 136.87 34.30 7
9AV2OBS2009-08-01 01:41:262009-08-01 01:44:08 00:02:42 74 139.91 74 149.76 0.00 -
10PSMOB22009-08-01 01:41:302009-08-01 01:44:20 00:02:50 74 140.16 74 150.49 0.00 -
11PSMOB22009-08-01 01:51:092009-08-01 01:56:13 00:05:04 74 175.35 74 193.82 0.00 -
12AV2OBS2009-08-01 01:51:152009-08-01 01:55:25 00:04:10 74 175.71 74 190.91 0.00 -
13PSRWB12009-08-01 02:11:332009-08-01 02:14:01 00:02:28 74 249.74 74 258.74 27.10 80
14PSRFBD2009-08-01 02:31:452009-08-01 02:45:15 00:13:30 74 323.40 120 12.64 34.30 43
15PSRFBD2009-08-01 02:53:142009-08-01 02:58:56 00:05:42 120 41.82 120 62.60 34.30 43
16AV2OBS2009-08-01 03:10:212009-08-01 03:13:09 00:02:48 120 104.18 120 114.39 0.00 -
17PSMOB22009-08-01 03:15:162009-08-01 03:34:06 00:18:50 120 122.10 120 190.79 0.00 -
18AV2OBS2009-08-01 03:19:362009-08-01 03:33:52 00:14:16 120 137.91 120 189.93 0.00 -
19PSRFBS2009-08-01 03:29:442009-08-01 03:32:28 00:02:44 120 174.86 120 184.83 34.30 7
20PSRWB12009-08-01 03:49:272009-08-01 03:51:11 00:01:44 120 246.76 120 253.08 27.10 80
21PSRWB12009-08-01 03:53:362009-08-01 03:56:22 00:02:46 120 261.90 120 271.99 27.10 80
22PSRFBD2009-08-01 04:03:532009-08-01 04:10:27 00:06:34 120 299.40 120 323.34 34.30 43
23PSRFBD2009-08-01 04:22:262009-08-01 04:27:06 00:04:40 166 7.05 166 24.07 34.30 43
24PSRFBD2009-08-01 04:31:582009-08-01 04:37:40 00:05:42 166 41.82 166 62.60 34.30 43
25PSRFBD2009-08-01 04:38:522009-08-01 04:41:40 00:02:48 166 66.98 166 77.19 34.30 43
26PSMOB12009-08-01 04:51:562009-08-01 05:09:22 00:17:26 166 114.63 166 178.20 1.20 -
27AV2OBS2009-08-01 04:55:522009-08-01 05:08:38 00:12:46 166 128.97 166 175.53 -21.50 -
28PSRWB12009-08-01 05:27:462009-08-01 05:34:54 00:07:08 166 245.30 166 271.32 27.10 80
29PSRPLR2009-08-01 06:07:532009-08-01 06:09:45 00:01:52 212 31.61 212 38.41 21.50 127
30PSRFBD2009-08-01 06:10:412009-08-01 06:16:23 00:05:42 212 41.82 212 62.60 34.30 43
31PSRFBD2009-08-01 06:17:482009-08-01 06:19:40 00:01:52 212 67.77 212 74.58 34.30 43
32AV2OBS2009-08-01 06:25:492009-08-01 06:28:37 00:02:48 212 97.00 212 107.21 0.00 -
33PSMOB12009-08-01 06:30:392009-08-01 06:41:35 00:10:56 212 114.63 212 154.50 1.20 -
34AV2OBS2009-08-01 06:37:022009-08-01 06:41:32 00:04:30 212 137.91 212 154.32 0.00 -
35PSRWB12009-08-01 06:42:512009-08-01 06:45:03 00:02:12 212 159.12 212 167.14 27.10 80
36PSRFBS2009-08-01 06:51:442009-08-01 06:56:18 00:04:34 212 191.51 212 208.17 34.30 7
37AV2OBS2009-08-01 06:52:102009-08-01 06:56:06 00:03:56 212 193.09 212 207.44 -34.30 -
38PSRFBD2009-08-01 07:53:072009-08-01 07:54:59 00:01:52 258 55.37 258 62.18 34.30 43
39PSRFBD2009-08-01 08:00:512009-08-01 08:03:07 00:02:16 258 83.57 258 91.84 49.00 51
40AV2OBS2009-08-01 08:13:412009-08-01 08:26:57 00:13:16 258 130.37 258 178.75 0.00 -
41PSRFBS2009-08-01 08:21:422009-08-01 08:23:34 00:01:52 258 159.61 258 166.41 34.30 7
42PSRFBD2009-08-01 12:19:512009-08-01 12:21:55 00:02:04 350 308.09 350 315.63 34.30 43
43PSRFBD2009-08-01 12:29:422009-08-01 12:33:50 00:04:08 350 344.01 350 359.08 34.30 43
44PSRFBS2009-08-01 12:34:512009-08-01 12:37:07 00:02:16 396 2.80 396 11.06 34.30 7
45PSRFBD2009-08-01 12:44:402009-08-01 12:51:16 00:06:36 396 38.59 396 62.66 34.30 43
46PSMOB12009-08-01 13:03:392009-08-01 13:06:49 00:03:10 396 107.82 396 119.37 1.20 -
47AV2OBS2009-08-01 13:23:192009-08-01 13:27:57 00:04:38 396 179.54 396 196.44 0.00 -
48PSMOB22009-08-01 13:25:302009-08-01 13:33:40 00:08:10 396 187.50 396 217.28 0.00 -
49PSRFBD2009-08-01 14:01:162009-08-01 14:31:40 00:30:24 396 317.93 442 68.80 34.30 43
50PSMOB12009-08-01 14:38:292009-08-01 14:50:21 00:11:52 442 93.66 442 136.94 1.20 -
51PSRWB12009-08-01 14:42:002009-08-01 14:44:56 00:02:56 442 106.48 442 117.18 27.10 80
52PSMOB22009-08-01 14:56:132009-08-01 15:08:13 00:12:00 442 158.33 442 202.09 0.00 -
53AV2OBS2009-08-01 14:58:292009-08-01 15:07:15 00:08:46 442 166.53 442 198.50 0.00 -
54PSRWB12009-08-01 15:22:252009-08-01 15:27:23 00:04:58 442 253.87 442 271.99 27.10 80
55PSRFBD2009-08-01 15:48:182009-08-01 16:08:36 00:20:18 442 348.26 488 62.30 34.30 43
56AV2OBS2009-08-01 16:29:152009-08-01 16:31:07 00:01:52 488 137.54 488 144.35 41.50 -
57PSMOB12009-08-01 16:33:282009-08-01 16:38:14 00:04:46 488 152.92 488 170.30 1.20 -
58PSRWB12009-08-01 17:03:542009-08-01 17:06:06 00:02:12 488 263.90 488 271.93 27.10 80
59PSMOB12009-08-01 17:53:592009-08-01 17:58:55 00:04:56 534 86.55 534 104.54 1.20 -
60PSMOB12009-08-01 18:01:402009-08-01 18:06:54 00:05:14 534 114.57 534 133.65 1.20 -
61PSRWB12009-08-01 18:09:382009-08-01 18:11:44 00:02:06 534 143.62 534 151.28 27.10 80
62PSRWB12009-08-01 18:39:002009-08-01 18:43:48 00:04:48 534 250.71 534 268.22 27.10 80
63PSRFBD2009-08-01 19:11:562009-08-01 19:17:08 00:05:12 580 10.82 580 29.78 34.30 43
64PSRFBD2009-08-01 19:19:472009-08-01 19:26:01 00:06:14 580 39.45 580 62.18 34.30 43
65PSRFBS2009-08-01 19:29:082009-08-01 19:31:40 00:02:32 580 73.54 580 82.78 34.30 7
66PSMOB12009-08-01 19:32:432009-08-01 19:35:47 00:03:04 580 86.61 580 97.79 1.20 -
67AV2OBS2009-08-01 19:33:132009-08-01 19:38:41 00:05:28 580 88.43 580 108.37 0.00 -
68PSMOB22009-08-01 19:40:152009-08-01 19:42:43 00:02:28 580 114.08 580 123.08 0.00 -
69AV2OBS2009-08-01 19:41:092009-08-01 19:45:01 00:03:52 580 117.36 580 131.46 0.00 -
70PSRWB12009-08-01 20:16:472009-08-01 20:23:29 00:06:42 580 247.37 580 271.80 27.10 80
71PSRFBD2009-08-01 20:39:342009-08-01 20:41:40 00:02:06 580 330.39 580 338.05 34.30 43
72PSRFBD2009-08-01 20:51:202009-08-01 20:55:12 00:03:52 626 13.31 626 27.41 34.30 43
73PSRFBD2009-08-01 20:58:422009-08-01 21:04:42 00:06:00 626 40.17 626 62.06 34.30 43
74PSRPLR2009-08-01 21:05:492009-08-01 21:09:15 00:03:26 626 66.19 626 78.71 21.50 127
75PSRFBD2009-08-01 21:10:352009-08-01 21:12:51 00:02:16 626 83.57 626 91.84 49.00 51
76PSRFBS2009-08-01 21:16:342009-08-01 21:21:40 00:05:06 626 105.33 626 123.93 41.50 10
77AV2OBS2009-08-01 21:16:512009-08-01 21:19:39 00:02:48 626 106.36 626 116.57 0.00 -
78PSRWB12009-08-01 21:54:572009-08-01 21:56:59 00:02:02 626 245.36 626 252.78 27.10 80
79PSRFBD2009-08-01 22:26:532009-08-01 22:42:37 00:15:44 1 1.76 1 59.14 34.30 43
80PSRPLR2009-08-01 22:44:032009-08-01 22:47:01 00:02:58 1 64.36 1 75.18 21.50 127
81PSRWB12009-08-01 22:50:112009-08-01 23:01:51 00:11:40 1 86.73 1 129.28 27.10 80
82PSMOB22009-08-01 22:56:442009-08-01 22:58:48 00:02:04 1 110.62 1 118.15 0.00 -
83PSRFBS2009-08-01 23:09:372009-08-01 23:11:29 00:01:52 1 157.66 1 164.47 34.30 7
84AV2OBS2009-08-01 23:10:052009-08-01 23:11:57 00:01:52 1 159.30 1 166.11 -34.30 -
85PSMOB12009-08-01 23:10:582009-08-01 23:15:44 00:04:46 1 162.52 1 179.91 1.20 -
86PSRWB12009-08-01 23:33:282009-08-01 23:41:00 00:07:32 1 244.64 1 272.11 27.10 80
87PSRFBS2009-08-01 23:42:342009-08-01 23:44:56 00:02:22 1 277.76 1 286.39 34.30 7

Node information(Nominal Time)

PathAscending NodeDescending Node
LongitudeTime(UTC)LongitudeTime(UTC)
28-14.779352009-07-31 23:24:19152.880852009-08-01 00:13:41
74-39.458942009-08-01 01:03:02128.201272009-08-01 01:52:24
120-64.138522009-08-01 02:41:46103.521692009-08-01 03:31:07
166-88.818102009-08-01 04:20:29 78.842112009-08-01 05:09:50
212-113.497692009-08-01 05:59:12 54.162522009-08-01 06:48:33
258-138.177272009-08-01 07:37:55 29.482942009-08-01 08:27:16
304-162.856852009-08-01 09:16:38 4.803362009-08-01 10:06:00
350172.463572009-08-01 10:55:21-19.876232009-08-01 11:44:43
396147.783982009-08-01 12:34:04-44.555812009-08-01 13:23:26
442123.104402009-08-01 14:12:47-69.235392009-08-01 15:02:09
488 98.424822009-08-01 15:51:30-93.914972009-08-01 16:40:52
534 73.745242009-08-01 17:30:13-118.594562009-08-01 18:19:35
580 49.065652009-08-01 19:08:57-143.274142009-08-01 19:58:18
626 24.386072009-08-01 20:47:40-167.953722009-08-01 21:37:01
1 -0.293512009-08-01 22:26:23167.366702009-08-01 23:15:44
